95 99 Al2O3 Alumina Ceramic Parts Structure Components / Oxide Ceramic Chamber

Product Categories
Dongguan Ming Rui Ceramic Technology Co.,ltd
Contact Now

95 99 Al2O3 Alumina Ceramic Parts Structure Components / Oxide Ceramic Chamber

Brand Name : Mingrui

Model Number : XF-1051

Certification : ISO9001-2015,

Place of Origin : China

MOQ : 10 pieces

Price : negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram, D/P, D/A

Supply Ability : 10000 pieces month

Delivery Time : 15-25 working days after the order confirmed

Packaging Details : intertional carton box

Name : Alumina oxide ceramic parts

Material : 95, 99 alumina ceramic

Type : Ceramic structure parts

Tolerance : Best to be 0.005mm

Secondary process : Fine grinding

Usage : Industry Usage

Precision : +/-0.001mm

Size : customized by customer

Flexural strength : 354 Mpa

Shape : bar, rod,tube or customized

Contact Now





95 99 Al2O3 Aluminum Oxide Ceramic Parts Structure Components / Ceramic Chamber

 Alumina ceramic parts Features:

1. Use temperatures up to 1500°C

2. High density

3. High hardness

4. Low thermal conductivity

5. Chemical inertness

6. Resistance to molten metals

7. Good Wear resistance

8. High fracture toughness

9. Shapes and size can be produced according to your requirements





Industrial ceramic can be processed in shaft , plunger, sealing structure, auto mobile Industrial parts, oil drilling equipment pieces, Insulation parts in electrical equipment , ceramic knife, ceramic flange parts,etc, with high density, bending strength and breaking tenacity.



Product Name
 95 99 Al2O3 Aluminum Oxide Ceramic Parts Structure Components / Ceramic Chamber
Material
Alumina ceramic
OD
0.3mm -50mm
Length
mm - 500mm
Surface Roughness
Ra0.05
Torlerance
+/- 0.001mm
Lead time
10 - 30days
Shipping
Air Express (DHL/UPS/TNT/ FedEx)






Properties Sheet of zirconia and alumina :



Properties Unit   Alumina Zirconia
96%Al2O3 99%Al2O3 99.5%Al2O3 99.8%Al2O3 99.9%Al2O3 3Y-TZP
Colour - White White Ivory Ivory Translucent white/black
Bulk density g/cc 3.78 3.88 3.93 3.93 3.98 6.03
Water Absorption % 0 0 0 0 0 0
Grain size μm 5-10 2-5 2-5 2-5 2-4 0.4
Bending strength MPa 380 350 360 380 300 1000
KIC MPa.m1/2 3~4 4 3~4 3~4 3~4 5~8
Vickers Hardness GPa 13 14 14.5 14.5 15 13
Young's Modulus of Elasticity GPa 360 370 370 380 390 200
Thermal Conductivity W/m° K 24 28 32 32 34 2
Coefficient of Linear Expansion 10-6/°C 6.7 7.2 7.2 7.2 7.2 10.5
Dielectric Constant (1MHz) - 9.1 9.5 9.6 9.6 9.9 33
Dielectric Loss Angle (1MHz) - 0.0002 0.0001 0.0001 0.0001 0.0001 0.002
Dielectric Strength V/m 15×106 15×106 15×106 15×106 15×106 11×106
Volume Resistivity Ohm.cm >1014 >1014 >1014 >1014 >1014 1013
(RT)




Packaging & Delivery

Packaging Details: 1. Carton with Bubble bag or foam.
2. Wooden carton
3. As per customer's requirements.
Delivery Details: 1. 3-25 days for sample
2. 25-40 days for mass products.
Shipment Terms: 1. Small order: By express, DHL/ UPS/ Fedex/ EMS etc.
2. Large order: By sea or By air

Quality assurance:

1. High heat resistance : Alumina ceramic has excellent thermal stability,which means that it is widely used in areas where resistance to high temperatures is essential.
2. Good wear resistance : Alumina ceramic is the material of choice for alumina wear parts.
3. High corrosion resistance : It is insoluble in water and only slightly soluble in strong acid and alkaline solutions. Good chemical stability of alumina leads to high corrosion resistance.

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
